AMPK activation induces immunogenic cell death in AML

Acute myeloid leukemia (AML) is an aggressive malignancy that arises from transformation of myeloid precursors. Although chemotherapy remains a cornerstone for the treatment of AML, new agents targeting molecular dependencies, such as fms-like tyrosine kinase 3 or B-cell lymphoma 2 (BCL2) inhibitors, are now available.¹ However, most patients still succumb to relapsed/refractory disease, demonstrating a need for new therapeutic strategies.

Immunotherapy in the form of allogeneic hematopoietic stem cell transplantation (allo-HSCT) is widely used to consolidate remission induced by cytotoxic agents in patients with AML. Nonetheless, major side effects including infections and graft-versus-host disease considerably limit the use of allo-HSCT, especially in the elderly.^2,3 As the antileukemic effects of allo-HSCT are mainly mediated by cellular immunity, new T-cell–activating immunotherapies are actively being investigated in AML, such as T-cell engaging antibodies, chimeric antigen receptors, and immune checkpoint inhibitors.⁴ However, antileukemic activity of these immunotherapies in AML appears to be modest, at least in studies to date.⁵

Among various modalities of cell death, immunogenic cell death (ICD) is relevant to cancer therapy because it promotes an antitumor immune response through tumor-specific antigenicity and adjuvanticity. This response is mediated by the release of damage-associated molecular patterns (DAMPs) that can activate dendritic cells (DCs) thus shaping the tumor immune microenvironment.^6,7 Cellular changes in response to environmental or internal signals are critical in the adjuvanticity of cells undergoing ICD, and the integrated stress response (ISR) pathway recently emerged as a hallmark of ICD.⁸

ISR pathways converge on phosphorylation of eukaryotic translation initiation factor 2 subunit alpha (eIF2α), which is also a characteristic feature of ICD.⁹ Protein kinase RNA-like endoplasmic reticulum (ER) kinase (PERK) is an eIF2α kinase that participates in ER stress response, which activates the transcription factor activating transcription factor 4 (ATF4) involved in cell death and autophagy.¹⁰ eIF2α phosphorylation is required for exposure of the ER chaperone calreticulin (CALR) at the cell surface, which serves as an activating “eat-me” signal for DCs.¹¹

Using the selective adenosine 5′-monophosphate–activated protein kinase (AMPK) activator GSK621, we recently showed that AMPK elicits a stress response through PERK and ATF4 activation, leading to enhanced mitochondrial susceptibility of AML to the BCL2 inhibitor venetoclax.¹² Because AMPK activation induces eIF2α phosphorylation through PERK activation, we hypothesized that AMPK activation might also trigger ICD in AML.

Here, we tested this hypothesis and found that GSK621 induced multiple features of ICD in AML. These effects were AMPK dependent, involved the activation of PERK, and were seen in human and mouse AML cells, including in immunocompetent syngeneic in vivo models of vaccination and tumor challenge. Together, our results show a new function of AMPK in regulating stress-induced ICD, suggesting the potential of AMPK activation to favor antileukemic immune activity.

Patient AML cells were from fresh or viably cryopreserved bone marrow aspirates collected at the time of diagnosis. All patients consented to an institutional review board–approved banking protocol. Clinical details are in supplemental Table 1.

Murine C1498 cells were purchased from the American Type Culture Collection (ATCC TIB-49) in 2018. Human AML cell lines were obtained from the ATCC between 2009 and 2015. Short tandem repeat profiling was performed periodically and mycoplasma negativity was verified yearly. Cells were cultured at 37°C in 5% CO₂ with minimum essential medium α (Gibco, 12561-072), supplemented with 10% fetal bovine serum (Sigma Aldrich, F2442), 1 mM L-alanyl-L-glutamine (Corning, 25-015-CI), 100 U/mL penicillin, and 100 μg/mL streptomycin.

To generate controls for surface CALR flow cytometry, C1498 cell lines were retrovirally transduced with a pRetro_CALR-DAF_DsRed,¹³ or Calr was deleted by CRISPR/CRISPR-associated protein 9 (Cas9). Cells were transfected with lentivirus containing single guide RNAs (sgRNAs) targeting Calr, or a nontargeting guide. For murine AML cells on a transgenic Cas9 background (see further sections), sgRNAs were cloned in the lentiviral vector pLKO5.sgRNA.EFS.tRFP (Addgene no. 57823), cells were infected, and red fluorescent protein–positive cells were sorted. sgRNA sequences: Calr (sgRNA no. 1: TATGTTTGGATTCGACCCAG; sgRNA no. 2: ATAGATGGCAGGGTCTGCGG; sgRNA no. 3: CGTAAAATTTGCCAGAACTG); Prkaa1 (sgRNA no. 1: CCTGTGACAATAATCCACAC; sgRNA no. 2: TGAAGGGTTTAAGTACTGAG; sgRNA no. 3: GAAGATTCGGAGCCTTGACG); Rosa26 (sgRNA no. 1: TGCAAGTTGAGTCCATCCGC; and sgRNA no. 2: GGGTAAAACGACTCCCCCAG); and nontargeting control (GGAGCGCACCATCTTCTTCA).

MOLM14 and OCI-AML2 cell lines were transduced with lentiviruses containing sgRNA targeting PRKAA1, or a nontargeting sequence.^14,15 For AMPK add-back, we transduced MOLM14 AMPK KO cells with a pLenti6–AMPK α1 1-312 that is not targeted by the PRKAA1 sgRNA (Addgene plasmid no. 162131).¹⁶

Virus was produced following standard methods in 293 T cells using Lipofectamine 2000 (Thermo Fisher no. 11668019) and either psPAX2 (second-generation lentiviral packaging plasmid; Addgene no. 12260) and pMD2.G (vesicular stomatitis virus glycoprotein envelope–expressing plasmid; Addgene no. 12259) for lentivirus, or pECO-PAC2 for retrovirus.

All animal experiments were performed with approval from the Dana-Farber Cancer Institute Institutional Animal Care and Use Committee. Murine ckit⁺ cells were sorted from whole bone marrow of Rosa26-Cas9 knockin C57BL/6J mice, transduced with mixed lineage leukemia-ALL1-fused gene from chromosome 9 (MLL-AF9) retrovirus and reinjected to sublethally irradiated C57BL/6J mice to generate a murine model of AML.¹⁷ Mice were monitored by peripheral blood sampling and euthanized when overt AML was diagnosed (>20% circulating green fluorescent protein–positive blasts or poor body condition). Briefly, single-cell suspensions from femurs and tibias of a leukemic mouse were harvested by spin isolation¹⁸ and seeded in methylcellulose media (Methocult, Stem Cell Technologies, M3234), supplemented with interleukin-6 (IL-6; 10 ng/mL), stem cell factor SCF (10 ng/mL), and IL-3 (6 ng/mL) (GoldBio). After serial replating, at a point when >90% of the colonies were granulocyte colony-forming units, cells were switched to liquid culture in media containing IL-3 (10 ng/mL, then 1 ng/mL). Cells were replated repeatedly, and the percentage green fluorescent protein–positive cells were regularly monitored until the AML cells were able to grow in cytokine-free media (Figure 1D). Dead cells were periodically removed by magnetic separation following the manufacturer’s instructions (Dead Cell Removal kit, Miltenyi Biotec, 130-090-101).

BMDCs were generated from bone marrow isolated from 8- to 10-week-old C57BL/6J mice.¹⁹ Cells were isolated from leg bones by centrifugation,¹⁸ then cultured in the presence of recombinant murine granulocyte-macrophage colony stimulating factor (20 ng/mL) for 7 days. Fresh culture medium supplemented with recombinant murine granulocyte-macrophage colony stimulating factor was added on day 3. On day 7, the percent CD11c⁺ cells (BMDCs) was determined by flow cytometry and used for further experiments.

On day 6 of BMDC differentiation, murine AML cells (C1498 or MLL-AF9 transformed cells) were treated with drugs or vehicle in a separate flask. On day 7 of differentiation, BMDCs and tumor cells were mixed at a ratio ranging from 1:2 to 1:20. After overnight coculture, BMDC activation was measured by flow cytometry using CD11c (marker of DCs), with CD80, CD86, and major histocompatibility complex II (MHCII; activation markers). As a positive control to induce activation markers without AML coculture, BMDCs were incubated with 0.1 μg/mL lipopolysaccharide (LPS) overnight.

Female C57BL/6J mice, 6- to 8-week old were obtained from The Jackson Laboratory. AML cells were treated in vitro with GSK621 30 μM or vehicle for 24 hours. After 24 hours, the cells were fixed in formalin 1% (in phosphate-buffered saline [PBS]) and then washed 5 times in PBS, as previously described.²⁰ After the last wash, cells were resuspended in PBS at 20 × 10⁶ cells per mL. Mice received a first subcutaneous injection of 100 μL (2 × 10⁶ fixed cells) in the left flank, followed by an identical boost 1 week later in the same flank. One week after the vaccination boost, the animals were challenged with 850 000 live cells resuspended in PBS-Matrigel (50:50), in the right flank. The group designated as unvaccinated received 100 μL of PBS only for the 2 vaccination steps. All subcutaneous injections were done under isoflurane anesthesia. For T-cell depletion, animals received intraperitoneal injections of 200 μg each of mouse anti-CD4 and anti-CD8 antibodies (InVivoMAb anti-mouse CD4, Clone: GK1.5, BioXcell no. BE0003-1; InVivoMAb anti-mouse CD8α, Clone 2.43, BioXcell no. BE0061), or immunoglobulin G (IgG) control antibody (InVivoMAb rat IgG2b isotype control, BioXcell no. BE0090). Injections of antibodies started 2 days before challenge and were continued until the end of the experiment. Tumor growth was monitored with digital calipers every 2 to 3 days. Tumor volumes were approximated as follows: volume = (width² × length) / 2, in which length is the longer tumor diameter, and width is the perpendicular tumor diameter. All experiments followed Institutional Animal Care and Use Committee–approved protocols. The study end points were defined per animal facility policies and required euthanasia for any mouse bearing a subcutaneous tumor reaching 2 cm in any dimension, an ulcerated tumor, or overall poor body condition or distress.

Cells were lysed in Laemmli buffer supplemented with dithiothreitol (50 mM) and sodium orthovanadate (2 mM). Blots were imaged using an Image Quant LAS-4000. Antibodies used were actin (MilliporeSigma, no. A5441); AMPKα (Cell Signaling Technology, no. 2532S); CALR (Cell Signaling Technology, no. 12238S); Cas9 (Cell Signaling Technology, no. 14697S); eIF2α (Cell Signaling Technology, no. 9722S); phospho-AMPKα (Thr172); Cell Signaling Technology no. 2535S); and phospho-eIF2α (Ser51; Cell Signaling Technology, no. 3398S).

Cells were washed in PBS (PBS 1×, pH 7.4; Gibco, 10010049) supplemented with 1% bovine serum albumin (Fisher BioReagents, BP1600100) and incubated with Fc block, following the manufacturer’s protocols (mouse: anti-mouse CD16-CD32, ThermoFisher Scientific, no. BDB553141; and Human BD Fc Block, no. 564219). Cells were stained with indicated antibodies for 30 minutes at 4°C in the dark.

Cells were washed in binding buffer 1× (annexin V–binding buffer, Thermo Fisher Scientific, BDB556454) and incubated for 15 minutes at room temperature in the dark with fluorochrome-conjugated annexin V and live/dead cell dye. Cells were analyzed using a CytoFLEX S (Beckman Coulter) or a BD LSRFortessa X-20. At least 10 000 events in the population of interest were recorded. Data were analyzed using FlowJo version 10.8 (BD Life Sciences). Reagents used were propidium iodide staining solution (ThermoFisher Scientific, no. BDB556463); 4′,6-diamidino-2-phenylindole (Cell Signaling Technology, no. 4083S); Zombie Green (BioLegend, no. 423111); Zombie Aqua (BioLegend, no. 423101); anti-CALR antibody, ER marker (Abcam, no. ab 2907); goat anti-rabbit IgG (H+L), secondary antibody Alexa Fluor 488 (Invitrogen, no. A-11034); Alexa Fluor 647 anti-CALR antibody (EPR3924), ER Marker (Abcam, no. ab196159); allophycocyanin anti-human CD45 (BioLegend, no. 368512); annexin V–Pacific Blue (BioLegend, no. 640918); allophycocyanin anti-mouse CD11c (BioLegend, no. 117310); Brilliant Violet 510 anti-mouse CD86 (BioLegend, no. 105039); PE anti-mouse I-A/I-E (MHCII) (BioLegend, no. 107607); and PerCP/cyanine5.5 anti-mouse CD80 (BioLegend, no. 104721).

Statistical analyses were performed using GraphPad Prism version 9, GraphPad Software, La Jolla, CA. Statistical tests used for each data presentation are specified in the legends.

We recently showed that AMPK activation by GSK621 induced a stress response through PERK activation and eIF2α phosphorylation.¹² Given that eIF2α phosphorylation is a hallmark of ICD, we hypothesized that GSK621 might elicit CALR membrane exposure and enhanced adjuvanticity in AML. First, we tested the effects of GSK621 on the C1498 murine AML cell line,²¹ derived from a spontaneous leukemia in a C57BL/6 mouse (supplemental Figure 1A). GSK621 induced dose-dependent apoptosis after 48 hours of exposure, similar to the effects seen in human AML cells¹⁴ (Figure 1A). Next, to establish controls for the specificity of surface CALR quantification by flow cytometry, we generated positive control C1498 cells with constitutive CALR membrane expression, or negative control cells with Calr KO using CRISPR/Cas9 (supplemental Figure 1B). We observed that CALR staining was similar to the isotype control in Calr KO cells, whereas signal intensity was markedly increased in cells with enforced CALR surface expression (Figures 1B; supplemental Figure 1C). Next, we treated parental C1498 cells with GSK621 and observed that CALR membrane expression increased within 6 hours, in a dose-dependent manner (Figures 1C; supplemental Figure 1D), supporting the hypothesis that AMPK activation induces ICD. CALR expression was also induced by mitoxantrone (MTO), an anthracycline known to induce ICD.²² In contrast, the antileukemic drug cytarabine (AraC) did not induce CALR membrane expression to the same level (Figure 1C), despite inducing a comparable degree of cell death (supplemental Figure 1E).

To test this hypothesis in a distinct and genetically defined AML model, we transduced bone marrow cells from C57BL/6 mice to express the human MLL-AF9 (also known as KMT2A::MLLT3) fusion oncogene. Subsequent transplantation into syngeneic recipient mice led to leukemia development, as performed previously.²³ We cultured the resulting mouse AML cells ex vivo in methylcellulose and performed serial replating to generate a murine AML cell line (designated, MLL-AF9 cells; Figure 1D). In these AML cells, GSK621 treatment for 48 hours induced dose-dependent apoptosis (Figure 1E), which was preceded by CALR surface exposure in viable cells at 24 hours of drug exposure (Figure 1F-G).

Finally, we exposed bone marrow samples from 3 patients with AML (supplemental Table 1) to GSK621. We observed increased CALR membrane expression in live bone marrow blasts at levels comparable with those induced by MTO (Figure 1H-I). Interestingly, induction of apoptosis and CALR exposure were detected on leukemia blasts but not on granulocytes and lymphocytes from the same bone marrow sample, which supports a potential therapeutic window (supplemental Figure 1F). Collectively, these results show that GSK621 induces an immunostimulatory DAMP in the form of CALR membrane exposure in murine and human leukemia cells.

To determine whether GSK621-induced CALR membrane exposure was AMPK dependent, we used MOLM-14 and OCI-AML2 human AML cell lines depleted of the AMPKα1 subunit by CRISPR/Cas9 editing (AMPK KO), which fully abrogates AMPK activity¹⁴ (Figure 2A). We observed that incubation with GSK621 had no impact on whole cell CALR protein abundance in AMPK KO or in control (nontargeting sgRNA; NTG) cells (supplemental Figure 2A). However, CALR cell surface expression was strongly induced by GSK621 in control but not in AMPK KO cells, arguing that GSK621-induced CALR membrane upregulation was on target (Figure 2B-C). GSK621 did not possess intrinsic fluorescence or promote isotype control staining, further supporting the specificity of cell surface CALR detection (supplemental Figure 2C). In contrast, CALR membrane exposure was strongly increased by idarubicin, an anti-AML chemotherapy known to induce ICD,²² in cells with or without AMPK (Figure 2D). Other anti-AML chemotherapies, such as cytarabine and venetoclax, had less impact on CALR membrane exposure (Figure 2D). Notably, all these agents caused comparable cell death in MOLM-14 cells at the same concentrations, supporting that specific cytotoxic drugs induce CALR exposure (supplemental Figure 2B).

To confirm target specificity, using AMPK KO cells, we re-expressed an active truncated form of AMPK (AMPK 1-312, missing an inhibitory domain¹⁶) that is not targeted by the AMPK sgRNA (Figure 2E-F; supplemental Figure 2D). Expression of AMPK 1-312 allowed membrane CALR induction in AMPK KO cells treated with GSK621 (Figure 2F). This was in contrast to treatment with venetoclax or cytarabine, which did not induce surface CALR regardless of AMPK expression status (Figure 2F). These data support a model in which CALR exposure can be induced in AML by specific agents and via AMPK-dependent or AMPK-independent pathways.

We recently showed that AMPK activation by GSK621 induces an ER stress response dependent on PERK activation.¹² Because the ISR is known to induce CALR membrane exposure and ICD,^9,24 we investigated the role of PERK in AMPK-induced CALR membrane expression. We used PERK KO MOLM-14 cells in which we could conditionally re-express PERK by a doxycycline-inducible construct.¹² We observed that PERK expression was important for eIF2α phosphorylation induced by GSK621 (Figure 2G). Moreover, CALR membrane expression was enhanced by GSK621 treatment in PERK-expressing MOLM-14 cells but was unaffected by PERK expression in the absence of GSK621 (Figure 2H). Collectively, these results show that AMPK activation by GSK621 induced ICD markers, including eIF2α phosphorylation and CALR membrane exposure, which were at least partially dependent on PERK.

Maturation of antigen-presenting cells is a surrogate readout of tumor cell immunogenicity in coculture experiments.²⁵ We examined the effect of GSK621-treated murine AML cells on syngeneic BMDCs in coculture assays ex vivo. We used LPS as a positive control to induce direct BMDC activation and maturation.²⁶ First, we incubated C1498 cells with vehicle (dimethyl sulfoxide), GSK621, MTO, or AraC. These cells were then cocultured with syngeneic BMDCs, and we measured DC activation by the co-expression of CD80/MHCII or CD86/MHCII among CD11c-positive BMDCs, using 2 ratios of DCs to tumor cells to mimic the heterogeneity of bone marrow infiltration in patients with AML (Figure 3A; supplemental Figure 3A). We observed that C1498 cells previously exposed to GSK621 or MTO significantly induced CD80 and CD86 expression on BMDCs to a level similar to that of LPS-treated BMDCs, whereas AraC-treated cells induced more modest BMDC maturation (Figure 3B-C). As an additional control, we used 3 cycles of freeze/thaw to induce nonspecific death in AML cells. We observed that a 1:1 or 1:10 ratio of DCs to freeze/thaw–killed tumor cells was insufficient to trigger BMDC activation (supplemental Figure 3B-C). We repeated this assay using GSK621-treated MLL-AF9 AML cells and similarly observed that coculture with BMDCs significantly induced CD80⁺ and CD86⁺ expression (Figure 3D). Together, these results show that AMPK activation in AML cells enables them to induce DC maturation.

To establish that AMPK activation results in clinically relevant ICD, we investigated the potential of GSK621-treated cells to facilitate an antitumor immune response in vivo using vaccination assays.²⁵ In these experiments, syngeneic murine AML cells were incubated in vitro with GSK621, and then injected subcutaneously into the left flank of immunocompetent C57BL/6 mice (vaccine site). After 7 days, we injected live AML cells into the right flank of vaccinated mice (challenge site), and followed tumor growth on the challenge site (Figure 4A). In the first experiment using C1498 AML cells, we observed that mice vaccinated with GSK621- or AraC-treated cells had significantly reduced tumor growth and improved tumor-free survival compared with unvaccinated mice (supplemental Figure 4A-B). However, there was no statistical difference between the GSK621 and AraC groups, possibly because of the rapid growth of C1498 cells in all assay arms using this model. Indeed, all animals vaccinated with dimethyl sulfoxide-treated cells had to be censored because they developed tumors at the vaccination site before the challenge site could be assessed. Nonetheless, using an enzyme-linked immunospot assay we confirmed that splenocytes from mice vaccinated with GSK621-treated AML produced interferon gamma when cultured specifically in the presence of parental leukemia cells (Figure 4B), which suggested the induction of tumor-specific cellular immunity.

To overcome the problem of aggressive growth of the untreated vaccine cells, we performed similar experiments using MLL-AF9–driven AMLs and modified our protocol by fixing treated cells before vaccination using 1% formalin, which is known to preserve the expression of cell surface molecules for tumor immunization.²⁰ We observed that the difference in CALR staining between GSK621 and vehicle-treated cells after fixation (supplemental Figure 4C) was similar to that seen in unfixed cells. Using this model, we observed an absence of tumor growth at the challenge site and 100% survival in the cohort of mice vaccinated with GSK621-treated AML cells, which was statistically improved compared with the other groups (Figure 4C-D). To explore the role of cellular immunity in the vaccination effect, we performed the same experiment in recipient mice treated with antibodies to deplete T cells before challenge. We reproduced the vaccination effect induced by GSK621-treated cells in immunocompetent mice receiving control IgG antibodies. In contrast, all CD4/CD8-depleted mice developed tumors that led to 100% mortality of this cohort, showing that the protective antitumor immune response induced by AMPK-activated leukemic cells was dependent on T cells in the vaccine recipients (Figure 4E-F). Collectively, these results indicate that AMPK activation by GSK621 elicits ICD in AML models.

AML has been treated by allo-HSCT for decades, a modality of immunotherapy in which graft-versus-leukemia activity is achieved by T cells and natural killer cells from the donor.²⁷ However, the antileukemic activity of allo-HSCT is, for the most part, inseparable from graft-versus-host disease, which causes considerable morbidity and mortality.²⁸ Therefore, improving cellular immunity to eradicate leukemic cells represents an important therapeutic goal. Directing T cells toward leukemia cells may be achieved by T-cell recruiting antibody constructs such as bispecific T-cell engagers against leukemia antigens, or by immune checkpoint inhibitors such as anti–programmed cell death protein 1 (PD-1)/programmed death ligand 1 antibodies.⁴ Moreover, autologous T cells can be modified to express chimeric antigen receptors targeting AML antigens such as CD33 and CD123.²⁹ However, although bone marrow–infiltrating T-cell number is preserved or even increased in patients with AML compared with in healthy individuals, these cells are functionally impaired.³⁰ This impairment may drive the disappointing results of T-cell immunotherapies to date. Immune evasion may involve defective antigen presentation, upregulation of checkpoint molecules, and other mechanisms of direct suppression of immune cells.³¹ Therefore, new strategies enhancing leukemia adjuvanticity could represent an improvement for AML immunotherapy.³²

Here, we showed that AMPK activation using the small molecule GSK621 resulted in the expression of an immunostimulatory DAMP in the form of CALR membrane exposure by murine and human AML cells. We previously demonstrated that AMPK activation induced a stress response involving the PERK/eIF2α/ATF4 signaling pathway, resulting in mitochondrial priming.¹² Interestingly, here we found that CALR membrane exposure induced by GSK621 in preapoptotic leukemic cells was dependent on AMPK and involved eIF2α phosphorylation. However, AMPK-induced CALR membrane expression was only partly dependent on PERK, suggesting that other effectors downstream of AMPK contributed to this immunostimulatory signal in AML. In melanoma, the stress kinases protein kinase R and general control nonderepressible 2 were shown to be key mediators of eIF2α phosphorylation in vitro³³ and might be pathways to explore in future work.

CALR surface exposure is associated with increased circulating natural killer, CD4⁺, and CD8⁺ cell populations including T cells directed against leukemia-associated antigens, and correlates with improved survival in patients with AML.³⁴ This suggests that pharmacological activation of AMPK to increase CALR could represent a new strategy to increase the anticancer immune response. We observed that idarubicin, a widely used anti-AML chemotherapy, also strongly induced CALR membrane exposure in AML, as reported,³⁵ and its effect was independent of AMPK. However, previous work demonstrated that PERK was necessary for anthracycline-induced surface CALR exposure,²⁴ which suggests a possible cross talk between the DNA damage response and ER stress, independent of AMPK.³⁶ The precise mechanism of ICD induction by other antileukemic therapies should be studied in future experiments.

This prompts the question of why we cannot simply rely on conventional chemotherapy to induce ICD in AML? In addition to causing myelosuppression and organ toxicity, anthracyclines have immunosuppressive activity by increasing regulatory T cells (Tregs) and tolerogenic DCs, which may limit antileukemia immunity.³⁷ Cytarabine reportedly modulates checkpoint molecules and possibly promotes AML immunogenicity.³⁸ However, we observed that cytarabine did not induce CALR membrane exposure to the same degree as GSK621, and it only modestly primed leukemic cells to trigger BMDC maturation ex vivo. Thus, the “3 + 7” induction regimen of anthracycline plus cytarabine that is the backbone of AML therapy has complex effects on immunity, which might still be enhanced by adding AMPK agonism. In further support of using AMPK activation as immune stimulation, AMPK loss in Tregs promotes tumor growth by increasing the expression of PD-1, whereas treatment of Tregs with the AMPK activator AICAR decreases PD-1 expression.³⁹ This suggests that AMPK activation could exert anticancer immunostimulatory effects on the tumor microenvironment as well as on AML cells. In fact, trials have reported activity by combining immune checkpoint blockade with metformin, an inhibitor of complex I mitochondria respiratory chain that stimulates anticancer immunity, in part, through AMPK activation.⁴⁰ Together, our results suggest that AMPK activation could represent an attractive strategy to kill AML blasts and simultaneously increase their adjuvanticity. Alternatively, addition of AMPK activation to conventional AML chemotherapies might enhance immunogenicity without relying solely on the AMPK activator for tumor debulking.

To establish that AMPK activation resulted in ICD, we used vaccination assays in AML models in syngeneic immunocompetent mice. Even though AML mainly spreads in the bone marrow and blood, we challenged vaccinated mice by the subcutaneous injection of leukemic cells, leading to the development of in situ tumors using established tumor immunology assays.¹⁴ This provided straightforward and reproducible measurements of tumor growth. In future studies, it may be important to test systemic leukemia growth, because AML cells may interact differently with the immune system in the bone marrow, blood, and in lymphoid organs such as the spleen. Despite these limitations, GSK621 pretreatment of either C1498- or MLL-AF9–driven AML cells induced a robust vaccination effect in vivo that was dependent on a T-cell systemic adaptive immune response specific to AML blasts.

In summary, we show that DAMP production by GSK621-treated AML cells primes BMDCs in vitro and elicits an adaptive T-cell immune response in vivo in immunocompetent hosts. This strategy could be exploited to increase AML adjuvanticity to improve endogenous immune responses and/or the efficacy of T-cell–based immunotherapies. The best timing of such treatments should be determined in clinical trials, possibly as an “immune priming” before, or during, initiation of induction chemotherapy, or later as part of consolidation. For instance, AMPK activation could be combined with other immunotherapies for patients who have achieved chemotherapy-induced remission, such as with DC-AML fusion vaccines⁴¹ or immune checkpoint blockade.
