Macrophage activation syndrome: characteristic findings on liver biopsy illustrating the key role of activated, IFN-γ-producing lymphocytes and IL-6- and TNF-α-producing macrophages

Macrophage activation syndrome (MAS) is a rare but often fatal condition, which characteristically presents acutely with nonremitting high fever, lymphadenopathy, hepatosplenomegaly, pancytopenia, liver dysfunction, hypertriglyceridemia, and hyperferritinemia. Coagulopathy and central nervous system dysfunction often ensue, and less frequently, the lungs, kidneys, and cardiac tissues are involved. The diagnosis is usually suspected on clinical and biochemical grounds and is supported by the finding of well-differentiated macrophages phagocytosing hematopoietic cells in the bone marrow.^1-3  The course of MAS is often dramatic, and fatality rates of 15% to 60%, despite prompt aggressive treatment, have been reported.^1-3

MAS is a descriptive term to designate the clinicopathologic entity that can occur in a varied group of diseases, which are now classified among the histiocytic disorders as the hemophagocytic syndromes (HSs).^4,5  Primary or familial hemophagocytic lymphohistiocytosis (primary HLH or FHL) is regarded as the prototype of HS and has a genetic basis, resulting in the inability of cytotoxic T lymphocytes (CTLs) or natural killer (NK) cells (or both) to efficiently kill target cells.⁶  Mutations in the perforin gene are found in 20% to 40% of patients with primary HLH.⁷  Secondary HS (also referred to as secondary HLH) designates MAS that complicates infections, malignancies, or inflammatory diseases such as juvenile idiopathic arthritis (JIA).^2,3  Evidence is emerging indicating that in patients with systemiconset JIA, preexisting impaired NK cell function may predispose to MAS.⁶

The sequence of events leading to MAS remains incompletely understood, but it is thought to be essentially the same in different types of HS.^3,6,8  Hypotheses on the pathogenesis of MAS are mainly derived from observations in primary HLH. In the acute phase, a lymphohistiocytic infiltrate is typically found, most commonly in the spleen, lymph nodes, and bone marrow.⁹  Furthermore, levels of circulating T-cell cytokines and monokines were found to be increased.¹⁰  These observations have led to the view that the inability of NK cells and CTLs to efficiently terminate an immune response, triggered, for example, by an infectious agent, leads to sustained activation of lymphocytes and macrophages. The result is widespread hemophagocytosis and overproduction of cytokines such as interferon γ (IFN-γ), tumor necrosis factor α (TNF-α), interleukin 1 (IL-1), and IL-6. Although this hypothesis is widely agreed on, it is largely based on indirect observations of excessive immune activation. We report on immunohistochemical findings on liver tissues of 5 children with MAS and provide direct evidence of massive infiltration by IFN-γ-producing CTLs and by macrophages, showing active hemophagocytosis and production of TNF-α and IL-6.

Five children presented with typical manifestations of MAS (Table 1). The diagnosis of MAS was established using the diagnostic guidelines developed and recently revised by the Histiocyte Society (Table 1).^1,5  In patients B, C, and D, bone marrow aspirates failed to reveal infiltration by mononuclear phagocytes or hemophagocytosis. To substantiate the diagnosis, liver histopathology was investigated on biopsies (patients B-E) or on a postmortem sample (patient A). In patient E, liver biopsy was taken to examine the dysfunctional liver graft. Biopsy procedures were performed with cover of platelet transfusions and fresh-frozen plasma. This study was performed with the approval from the University Hospital Gasthuisberg Institutional Review Board. Tissues were obtained from patients after informed consent was provided according to the Declaration of Helsinki.

Liver biopsy specimens were partially embedded in paraffin and partially snap frozen in isopentane, cooled in liquid nitrogen. Hematoxylineosin (HE) stain and immunohistochemical stainings were performed as described.¹²  Primary antibodies used were mouse monoclonal anti-CD4, anti-CD8, anti-HLA-DR, anti-TNF-α (Becton Dickinson Biosciences, Erembodegem, Belgium), and anti-CD68 antibodies (Dako, Glostrup, Denmark); rabbit polyclonal anti-IL-6 antibody (Genzyme, Zaventem, Belgium); mouse monoclonal anti-IFN-γ antibody (D9D10),¹³  kindly provided by I. Ronse, Rega Institute, Leuven, Belgium). Specimens were counterstained with Mayer hemalum.

In patients A, B, C, and E, liver biopsy specimens were taken in the early stage of MAS. Histologic and immunohistochemical findings were similar in all 5 patients; Figure 1A and Figure 1C-H show representative images. HE staining revealed massive infiltration of portal tracts and sinusoids by mononuclear cells (Figure 1A). Immunohistochemical stainings showed numerous CD68⁺ macrophages (Figure 1C) and CD8⁺ lymphocytes (Figure 1G), expressing HLA-DR (not shown). Only few cells stained positive on CD4 staining (not shown). Lymphocytes expressed IFN-γ (Figure 1H) and macrophages expressed TNF-α (Figure 1E) and IL-6 (Figure 1F). Hemophagocytosis was recognizable on HE staining and was unequivocally detected in the cytoplasm of CD68⁺ macrophages (Figure 1D).

Patient D had experienced several febrile episodes before liver biopsy was performed. Although HE stain failed to reveal a massive mononuclear infiltrate (Figure 1B), the CD68 stain revealed the presence of numerous macrophages, showing active hemophagocytosis and expression of TNF-α and IL-6 (Figure 1C-F).

Previous studies have addressed the phenotype of the infiltrating cells in MAS and showed histiocytes to be of the monocyte/macrophage lineage, and the lymphocytic infiltrate to be composed mainly of T cells.^14,15  Henter et al studied 9 children with primary HLH and found elevated serum levels of IFN-γ, TNF-α, IL-6, and soluble CD8.¹⁰  Others also reported on the occurrence of high levels of IL-1, granulocyte-macrophage colony-stimulating factor (GM-CSF) and soluble IL-2 receptor (IL-2R) in serum/plasma of patients with various HSs.^16-18  Akashi et al found that CD2⁺ circulating lymphocytes from patients with primary HLH spontaneously secreted IFN-γ in vitro, and monocytes TNF-α and IL-6.¹⁸  Our report directly substantiates the presumed immunopathogenesis of MAS by documenting in situ expression of IFN-γ by activated CD8⁺ lymphocytes, and of IL-6 and TNF-α by hemophagocytosing macrophages, on liver tissues of patients with MAS. Our findings are in agreement with the recent report by Jordan et al, who used perforin-deficient mice to show that CD8⁺ lymphocytes and IFN-γ play a pivotal role in lymphocytic choriomeningitis virus-induced HLH.¹⁹

Although all patients suffered from a different type of HS, their liver biopsy specimens showed a strikingly similar pattern of infiltrating cell types and cytokine expression. This is consistent with the view, now shared by rheumatologists and hematologists, that MAS has a unique pathogenesis, irrespective of cause or eliciting factors.^3,4,8  In patient D, liver biopsy was performed in a later, persistently active, stage of MAS; the cellular infiltrate consisted predominantly of hemophagocytosing macrophages, whereas lymphocytes were present in smaller numbers. Of interest, it was only after the addition of anti-CD3 to the treatment that MAS remitted. Likewise, treatment with basiliximab resulted in transient improvement in patient E. These observations underscore the primary role of activated T cells in the pathogenesis of MAS.

Reportedly, the pathologic picture of liver tissue from patients with HS is consistent with chronic persistent hepatitis.²⁰  Ost et al found a chronic hepatitis-like picture in postmortem specimens from 22 of 27 primary HLH patients.²¹  Favara et al reviewed the liver histopathology of 32 children with various HS.²²  Portal infiltrates were seen, with numerous T lymphocytes and few histiocytes. Massive infiltration by activated macrophages, as seen in our series, was not reported on, but Kupffer cells appeared enlarged and showed, in about half the specimens, hemophagocytosis. In our experience, macrophage-specific stainings were not only necessary to demonstrate the presence of macrophages/Kupffer cells, they also facilitated the detection of hemophagocytosis.

The frequent occurrence of coagulopathy in acute MAS poses a considerable risk to performing biopsies of target organs other than the bone marrow, and the authors restrain from proposing liver biopsy as a routine diagnostic investigation for MAS. However, in this particular group of patients, the necessity of obtaining conclusive evidence of MAS and of excluding other pathology, justified the risk of performing a liver biopsy.

In conclusion, this study on 5 patients with different types of HS is the first to deliver direct evidence on the involvement of activated, IFN-γ-producing CD8⁺ lymphocytes, and of TNF-α- and IL-6-producing macrophages, in the pathogenesis of MAS. Our findings support the prevailing hypothesis on the immunopathogenesis of this syndrome and underscore the view that MAS in different types of HS share a common inflammatory effector pathway.
