Distinct platelet packaging, release, and surface expression of proangiogenic and antiangiogenic factors on different platelet stimuli

Platelets contribute importantly to multiple physiologic/pathophysiologic processes beyond thrombosis and hemostasis, such as inflammation, angiogenesis, and atherogenesis.^1-4  Platelets store and release a number of regulators that modulate angiogenesis.^5-7  It has recently been shown that platelets store proangiogenic and antiangiogenic factors in separate α-granules⁸  and release them selectively on the thrombin receptor PAR1 and PAR4 stimulation.^8,9  Platelets can also selectively sequester angiogenic regulators.^10,11  We have further characterized differential release and surface expression of platelet proangiogenic stromal cell-derived factor-1α (SDF-1α/CXCL12) and vascular endothelial growth factor (VEGF) and antiangiogenic platelet factor 4 (PF4/CXCL4) and endostatin in response to different platelet stimuli.

Twenty-four healthy and medication-free volunteers (12 females, 25-64 years of age) gave informed consent to participate in the study, which was approved by Ethics Committee of the Karolinska Institutet.

Immunofluorescent staining of citrated platelet-rich plasma (PRP) was performed as previously described.⁸

Immunogold electron microscopic platelet samples were prepared as previously described.⁸  Platelet images were acquired using a Leo transmission electron microscope.¹²

Citrated whole blood or PRP was labeled at 22°C without or with platelet agonists and intracellular signaling inhibitors. Flow cytometric platelet analyses were performed as previously described.¹³

Washed platelets (3 × 10⁸/mL) were stimulated, and the supernatant was collected and aliquoted after centrifugation (14 000g, 5 minutes, 4°C). The levels of VEGF, SDF-1α, PF4, and endostatin were determined using corresponding DuoSet ELISA kits (R&D Systems).

Data are presented as mean plus or minus SEM. Comparisons were performed with Student paired t test.

Immunofluorescent staining showed that each of the angiogenic factors was stored in granules randomly distributed in unstimulated platelets (Figure 1Ai,Bi,Ci,Di). On stimulation, the granules were mobilized toward cell periphery, often seen in a ring-like staining pattern (arrows) and with reduced immunofluorescence intensity compared with resting platelets (Figure 1Aii-v,Bii-v,Cii-v,Dii-v). Double immunofluorescence labeling demonstrated that most SDF-1α (red) and PF4 staining (green) was in separate granules, with some colocalization seen in yellow (arrowheads) in both resting (Figure 1Eiii) and adenosine diphosphate (ADP)-stimulated platelets (Figure 1Fiii). Immunogold electron microscopy revealed that SDF-1α (Figure 1G) or PF4-probing gold particles (Figure 1H) do not present in all α-granules and that only some α-granules contain both SDF-1α (arrows) and PF4 (arrowheads) gold particles (Figure 1I), supporting our findings with confocal microscopy and the notions that the counteracting factors are mostly segregated in separate α-granules⁸  and that different α-granules are packed with different proteins.¹⁴

Platelet activation evokes distinct secretion and surface expression of angiogenic factors. Stimulation with PAR1-AP, ADP, and collagen related peptide (CRP, targeting glycoprotein VI [GPVI]) induces massive release of SDF-1α and VEGF, as evidenced by marked reductions of immunofluorescent intensities (Figure 1Aii, iv,v;Cii,iv,v) and significant elevations of SDF-1α (Figure 2A) and VEGF levels (Figure 2B) in the supernatant of washed platelets. Semiquantitative flow cytometric analysis of permeabilized platelets showed that SDF-1α staining index (positive % × mean fluorescent intensity) was reduced by 50% in PAR1-stimulated (210.8 ± 37.8 vs 459.4 ± 76 in resting platelets) and by 35% in PAR4-stimulated platelets (240.7 ± 39.0; n = 3). These agonists induced, however, much less release of the antiangiogenic PF4 (Figures 1Bii,iv,v,2C) or actually no release of endostatin (Figure 2D), although endostatin-containing α-granules were still mobilized toward the periphery of platelets (Figure 1Dii,iv,v). The data indicate that PAR1-AP, ADP, and CRP selectively enhance proangiogenic factor release. Furthermore, the combination of ADP and a P2Y12 antagonist showed that ADP-induced VEGF and PF4 release was mainly via P2Y12 activation, whereas ADP-induced SDF-1α secretion was primarily via P2Y1 receptor engagement. In contrast, PAR4-AP triggered marked release of PF4 (Figures 1Biii, 2C) and endostatin (Figures 1Diii,2D) but limited release of SDF-1α (Figures 1Aiii,2A) and VEGF (Figures 1Ciii,2B). Thus, PAR4-AP stimulation promotes a selective release of platelet antiangiogenic factors. Furthermore, platelet secretion of angiogenic factors seems to be a rapid process. The maximal PAR1-stimulated VEGF release was reached in less than 5 minutes, with VEGF levels increased from undetectable of resting platelets to 49.8 ± 1.8, 50.6 ± 0.6, and 49.9 ± 0.6 pg/mL at 5, 15, and 30 minutes of stimulation, respectively. Similarly, PAR4-stimulated endostatin release peaked at 5 minutes (89.1 ± 10.6 vs 0.9 ± 0.1 ng/mL of resting platelets, and 81.3 ± 11.9 ng/mL after 30 minutes stimulation; n = 3).

In parallel with increased platelet P-selectin expression, all tested agonists markedly and dose-dependently elevated platelet surface expression of SDF-1α and endostatin but induced mild PF4 or no VEGF expression (Figure 2E-H). Interestingly, platelet surface expression of these angiogenic factors, especially SDF-1α and endostatin, did not completely synchronize with their milieu release. For instance, all agonists markedly enhanced platelet SDF-1α and endostatin expression (Figure 2E-H), but only PAR4-AP (D) induced endostatin secretion. This may account for the poor correlation between platelet surface expressed and plasma levels of SDF-1α.¹⁵  Enhanced platelet SDF-1α surface expression is angiogenically important and can enhance endothelial progenitor cell recruitment at the arterial injured sites.¹⁶

Platelet secretion involves multiple signaling pathways.^17,18  We show here that, despite equally activated (as measured by platelet P-selectin expression, 81.3% ± 1.1% by PAR1 and 81.2% ± 0.4% by PAR4) and triggering similar intracellular signalings,¹⁹  PAR1- and PAR4-induced SDF-1α and endostatin secretion showed different dependency on multiple signaling pathways. Thus, Src blockade markedly inhibited PAR1-induced, but only modestly attenuated PAR4-induced, SDF-1α secretion. In contrast, blockade of phosphatidylinositol 3-kinase, Akt, protein kinase C (PKC), mitogen-activated protein kinase kinase, and p38 showed more profound inhibition on PAR4-induced SDF-1α secretion, whereas mitogen-activated protein kinase kinase or p38 blockade did not influence the PAR1 effect (Figure 2I). The better inhibitions on PAR4 effect are not simply because PAR4 stimulation induces less SDF-1α secretion. PAR4-induced massive endostatin release was also markedly inhibited, and Akt and PKC blockade almost abolished the release (Figure 2J, in which PAR1 induced no endostatin release, 3.6 ± 0.4 ng/mL vs 3.5 ± 0.4 ng/mL of unstimulated platelets, and effects of the inhibitors are thus not plotted). Notably, none of these signaling regulators markedly attenuated platelet surface expression of P-selectin (Figure 2K), SDF-1α (eg, 25.3% ± 6.0% and 26.7% ± 6.4% by PAR1 stimulation without or with PKC blockade; n = 5), or endostatin (28.4% ± 6.6% and 26.8% ± 6.1% by PAR4 stimulation without or with PKC blockade; n = 5). This is probably because P-selectin is a general marker of platelet secretion, and a trace of platelet-released SDF-1α and endostatin can efficiently bind on their specific receptors (eg, CXCR4 and integrin α4β1) on platelet surface.^16,20,21  It should also be noted that those inhibitors did inhibit P-selectin expression at lower agonist concentrations (eg, 5μM PAR1-AP or 50μM PAR4-AP), which are insufficient to induce optimal release of platelet angiogenic factors (data not shown).

Taken together, PAR1, P2Y12, P2Y1, and GPVI stimulation favors platelet release of proangiogenic factors. PAR4 stimulation selectively induces platelet secretion of antiangiogenic factors. PAR1-induced SDF-1α secretion depends on mitogen-activated protein kinase signaling little, whereas Akt and PKC signaling is critical for PAR4-induced endostatin release. Distinct platelet secretion of angiogenic factors may be an important angiogenesis-regulating mechanism. Platelets adhere at the sites of vascular injury. They react to the early stimuli (eg, subendothelial collagen, low concentrations of initially generated thrombin that activates platelets via the high-affinity PAR1, and self-released ADP) and release proangiogenic factors. As thrombus builds up, platelets react to the late stimulus, high concentrations of thrombin that accumulate within platelet clots, via the low-affinity PAR4 to promote antiangiogenic regulator release. Hence, platelets may locally and dynamically modulate angiogenic balance.

The authors thank Maud Daleskog and Ragnhild Stålesen for expert technical assistance.

This work was supported by grants from the Swedish Research Council, the Swedish Heart-Lung Foundation, the Stockholm County Council, the Swedish Society of Medicine, and the Karolinska Institutet.

Contribution: M.C., Z.H., and W.Z. designed and performed the research, interpreted the data, and drafted the manuscript; L.J., L.Z., and H.H. performed the research, interpreted the data, and revised the manuscript; K.H. performed the research and interpreted the data; G.P.N. designed the research, interpreted the data, and revised the manuscript; and N.L. designed and supervised the research, interpreted the data, and wrote the manuscript.

Conflict-of-interest disclosure: The authors declare no competing financial interests.

Correspondence: Nailin Li, Karolinska Institutet, Department of Medicine-Solna, Clinical Pharmacology Unit, Karolinska University Hospital (Solna), SE-171 76 Stockholm, Sweden; e-mail: Nailin.Li@ki.se.
